SUPER AEROCRANE
High Capacity Fixed Arm Crane
8'-35'
Variable reach
350 LBS
Max Payload
33'
Max Height
10 LENGTHS TO FIT YOUR NEEDS
With a maximum reach of 35', the Super Aerocrane 35 is one of the most sought-after fixed arm cranes in the industry. This crane can be built in varying lengths from 8' to 35' in reach. Equipped with a Mitchell nose, it pairs well with any of our stabilized remote heads, such as our Movi XL or our Mo-Sys L40, either in underslung or overslung mode. Pair it with a Mitchell to junior adapter to fly lights!
Treefort offers the Super Aerocrane 35 with one of two different base options -
the Aerobase or the Moviebird Scissoring Trackable base.
REACH | TOTAL LENGTH | MAX PAYLOAD | MAX HEIGHT |
|---|---|---|---|
8' | 16' | 160 LBS | 12'-5" |
11' | 19' | 130 LBS | 14'-9" |
14' | 22' | 350 LBS | 17'-2" |
17' | 25' | 305 LBS | 19'-7" |
20' | 29' | 350 LBS | 22' |
23' | 31' | 285 LBS | 24'-4" |
26' | 36' | 280 LBS | 26'-9" |
29' | 39' | 205 LBS | 29'-2“ |
32' | 42' | 160 LBS | 31'-7" |
35' | 45' | 115 LBS | 34' |
VERSATILE
CONFIGURATIONS
Reach: Length from Fulcrum to Mitchell Nose
Total Length: From Bucket to Mitchell Nose
Max Payload: Maximum weight on Mitchell Nose
Max Height: Length from ground to Mitchell Nose at maximum tilt (52°) with the fulcrum mounted 6 feet off the ground.
SETUP & TRANSPORT
.png)
Weight of cases:
1,180 LBS
820 LBS
Full crane contained in
2 CASES
3 WEIGHT CARTS
.png)
First time using the crane?
COME BY FOR
A DEMO
Sets up in
ABOUT
3O MINUTES
PAIR IT WITH...
Compatible with Mitchell or Euro mounts!
Aerocrane
Aerocrane's own mobile base with a telescoping center column. Capable of going on track.
.png)
SUPER AEROCRANE
TECHNICAL DRAWING
